Customize your bandsaw
Bandsaw table options
Our cutting tables are designed to solve unique requirements in various working environments. If you require a custom solution, please contact us.
![](https://cdn.prod.website-files.com/658293272e88def35a55b74f/65a6601838f789ac7fe0dd0c_chute-table-bg.webp)
Static table
The static table is the most common table installed on Guardian Bandsaws. Tables are split into an inside and outside leaf that open easily for blade changes.
Table Number
Dimension A
Dimension B
Dimension C
1113235
350mm
450mm
500mm
1113234
500mm
400mm
500mm
1113248
500mm
780mm
500mm
1113289
350mm
780mm
500mm
![](https://cdn.prod.website-files.com/658293272e88def35a55b74f/65a660190fa2f99d121cca21_heated-table-bg.webp)
Heated table
Heated tables are used to reduce sliding friction on the tabletop. This is a great alternative to applying water to the table, which can have a negative impact on product shelf life.
Table Number
Dimension A
Dimension B
Dimension C
1114046
350mm
400mm
500mm
1125915
500mm
400mm
500mm
![](https://cdn.prod.website-files.com/658293272e88def35a55b74f/65a6601838f789ac7fe0dd0c_chute-table-bg.webp)
Chute table
Chute tables are used when an operator cuts a product into a bin. Operators can move the chute to any angle in seconds with no tools.
Table Number
Dimension A
1113235
350mm
1113235
350mm
1113235
350mm
1113235
350mm
![](https://cdn.prod.website-files.com/658293272e88def35a55b74f/664de605a70d9240564ca076_Tilting%20table.png)
Tilting table
Ideal for cutting compound angles for industrial use cases. Cut 0-45° angles with high accuracy.
Slide tables
Slide tables are for slicing, T-Bone, and beef loin cutting. These are a great way to increase cutting accuracy and efficiency. All slide tables use the same sliding element and inside leaf. Below is the range of pusher blocks and thickness guides that are available.
Size options
460mm
Commonly used in case ready plants
![](https://cdn.prod.website-files.com/658293272e88def35a55b74f/6594168c372b8e57c5584550_a-slide-table.png)
600mm
Commonly used in slaughter plants for large cuts
![](https://cdn.prod.website-files.com/658293272e88def35a55b74f/65a535c6c6c2eab61ad2fba2_600mm-slide-table-2.webp)
Thickness guide options
Fine adjustment
![](https://cdn.prod.website-files.com/658293272e88def35a55b74f/65a5370156ad239cd10ab52a_Fine-adjustment-thickness-guide.webp)
T-Bone
![](https://cdn.prod.website-files.com/658293272e88def35a55b74f/65a537016498f8a5f697287c_T-bone-thickness-guide.webp)
Removable
![](https://cdn.prod.website-files.com/658293272e88def35a55b74f/65a537013769338c8270cff8_removable-thickness-guide.webp)
Sliding element attachment options
Plastic pusher
Most common slide table attachment
![](https://cdn.prod.website-files.com/658293272e88def35a55b74f/65a537a4ee36d93430af7b24_pusher-block.webp)
Meat clamp
Ideal for portioning
![](https://cdn.prod.website-files.com/658293272e88def35a55b74f/65a537a4e6e57e25bbc355f5_meat-clamp.webp)
Welded tab
Welded to either end or outside the table
![](https://cdn.prod.website-files.com/658293272e88def35a55b74f/65a537a426233f4d9267c8f0_welded-end-tab.webp)
Static insert
Commonly used in Case Ready plants
![](https://cdn.prod.website-files.com/658293272e88def35a55b74f/65a537a44291a24179d51df8_fixed-top.webp)
Common slide table configurations
T-Bone
Most common slide table attachment
![](https://cdn.prod.website-files.com/658293272e88def35a55b74f/65a53883f962b54e45fea9f2_t-bone-table.webp)
Fine adjustment
Plastic pusher block and fine adjustment thickness guide
![](https://cdn.prod.website-files.com/658293272e88def35a55b74f/65a5386de044bdb3d723f22e_Fine-adjustment-thickness-guide.120-scaled%20(1)-PhotoRoom.png-PhotoRoom.webp)
Configurable
Meat clamp, removable thickness guide, and static insert.
